DVP08SM11N – S Series Delta Digital Module – DI 8
EGP 0
DESCRIPTION
DVP08SM11N Series-S Expansion Module DVP
Input: 8 Sink/Source 24VDC
Usable with SS / SA / SE / SX / SV / MC PLCs
I/O extension unit that can be connected to the right of the CPU/MPU to add inputs and/or outputs as required
Main features
8 inputs extension modules
Simply plug it in and draw power from the main MPU
General extension (right side) – High-speed extension (left side)
