المنتجات
DVP16SN11T
Slim Series Extension Module
16DO
Transistor Output
Product category PLC
sub-category DVP Slim Series
Partner name Delta
Series name DVP-Slim Expansion
Attributes
PLC Module Expansion Module
I/O Selection Separate DI/DO
.Supply N.A
Output Type Transistor
In Built NO
DVP28SV211R
High Performance Slim PLC
High-speed pulse output: 4 axes of 200 kHz pulse output
Supports 4 hardware 200 kHz high speed counters
32-bit CPU + ASIC dual processors support floating point operations
Max. execution speed of basic instructions: 0.24μs
Product category PLC
sub-category DVP Slim Series
Partner name Delta
Series name DVP-SV2
Attributes
PLC Module CPU
I/O Selection Mix DI/DO
Supply 24VDC
Output Type Relay
In Built NO
لوحة تدريب الأنظمة المدمجة الأساسية V2.101
| الفئة | المكون (Training Module) |
|---|---|
| المتحكم الرئيسي | ATmega2560-16AU |
| شاشة عرض | 16×2 LCD |
| شاشة عرض رقمية | 7-Segment Display (4×1) |
| الاتصال اللاسلكي | Bluetooth Module |
| التخزين | SD Card Module |
| مستشعر الحركة | PIR Motion Sensor |
| مستشعر الحرارة | DS18B20 Temperature Sensor |
| مستشعر الحرارة والرطوبة | DHT11 Sensor |
| لوحة مفاتيح | 4×4 Keypad |
| وحدة ريلاي | 3-Channel Relay Module |
| قيادة المحركات | DC Motor Driver |
| محرك تيار مستمر | DC Motor |
| التعرف على الهوية | RFID 13.56 MHz Module |
| محرك تيار متردد | AC Motor |
| التحكم عن بعد | Infrared Remote Control |
| مؤشرات الإضاءة | LED Indicators |
| التحكم في الأحمال | Triac Module |
| وحدة الساعة | RTC (Real-Time Clock) Module |
| أزرار التحكم | Push Buttons |
| التنبيه الصوتي | Buzzer |
| مستشعر الإضاءة | LDR (Light Dependent Resistor) |
| مقاومة متغيرة | Potentiometer |
G2156E2
Performance Specification
Display size 15.6" TFT
Display area 344.16mm(W)x193.59mm(H)
Resolution 1920*1080px
Display color16.7M
Visual angle 80/80/80/80(L/R/U/D)
Contrast 1000:1
Backlight LED
Luminance 250cd/m²
LCD life ＞20000 hours
Touch panel 4 line precision resistance network（surface hardness 3H）
CPU Quad-core 1.5GHz
Memory 4GB Flash Memory+512MB Memory
RTC Built-in
External storage 1 USB Host
Printer port USB Host/Serial port
EthernetLAN0: 10/100 Mbps; LAN1:10/100 Mbps
Program download Ethernet port/USB Slave/U disk
Communication COM0:RS232/RS485/RS422;COM2:RS232;
GL070E
Performance Specification
Display size 7" TFT
Display area 154.08(W)×85.92(H)
Resolution 800×480 px
Display color 16.77M true color
Visual angle 70/70/60/70(L/R/U/D)
Contrast 500:1
Backlight LED
Luminance 450cd/m²
LCD life More than 30000 hours
Touch panel 4-wire precision resistance network (surface hardness 4H)
CPU ARM RISC 32Bit 800 MHz
Memory 256MB Flash Memory+128MB Memory
RTC Built-in RTC
External storage 1USB Host
Printer port USB Host/Serial port
Ethernet 10/100M adaptable Ethernet interface
Bus interface None
Program download USB Slave(Micro USB)/U Disk/EthernetCommunication COM0: RS232/RS485/RS422.COM2: RS232
Good Quality CNC Servo Motor 3kw 220V High Speed 2000rpm AC Servo Motor for Milling
Basic Info
Model NO. 130SE
Application Industrial
Speed High Speed
Number of Stator Three-Phase
Function Driving, Control
Casing Protection Protection Type
Number of Poles 6
Starting Mode Motor Drive Control
Certification ISO9001
Brand Holry
Trademark HOLRY
Transport Package Wooden Box; Carton
Specification 130SE
Origin China
HS Code 8501200000
Houle 1.5kw 220V 5.1A 110A 1500rpm Series Servo Motors
Basic Info
Model NOSH4MA 110A-100CF12D-01
Number of Stator Three-Phase
Function Driving
Casing Protection Closed Type
Number of Poles 20 54
Starting Mode Direct on-line Starting
Certification ISO9001, CCC, CE
Brand Houle
Safety Class IP65
Power 1.5kw
Rated Speed 1500pm
Rated Current 6.3A
Rated Voltage 220V
Flange Specifications 110A
Insulation Class Classf
Transport Package CTN
Specification 10.9KG
Trademark HOULE
Origin China
HS Code 8501510090
Production Capacity 3000PCS/Month
لوحة تدريب الأنظمة الهيدروليكية V4.402
MT043E
Performance Specification
Display size 4.3" TFT
Resolution 480*272 px
Display color256K color
Visual angle 70/70/50/70(left/right/up/down)
Backlight LED
Luminance 450cd/m²
LCD life 50000 hours
Touch panel 4-wire precision resistance network (surface hardness 4H)
CPUARM RISC 32Bit 792MHz
Memory 128MB Flash Memory+64MB Memory
RTC Built-in
External storage 1 USB Host
Printer port USB Host/Serial port
Ethernet 10/100M adaptable Ethernet interface
Program download USB Slave(Micro USB)/Serial port
Communication COM0:RS232/RS485/RS422; COM2:RS232
MT070/MT070E/MT070E-4G
Performance Specification
Display size 7" TFT
Resolution 800×480 px
Display color 256K color
Visual angle 70/70/50/70
Backlight LED
Luminance 250cd/m²
LCD life 50000 hours
Touch panel 4-wire precision resistance network (surface hardness 4H)
CPU ARM RISC 32Bit 792MHz
Memory 128MB Flash Memory+64MB Memory
RTC Built-in RTC
External storage 1 USB Host
Printer port USB Host/Serial port
Ethernet None
Program download USB Slave(Micro USB)/Serial port
Communication COM0:RS232/RS485/RS422; COM1:RS485;COM2:RS232
MT100/MT100E/MT100E-4G
Performance Specification
Display size10.1" TFT
Display area 222.72(W)x 125.28(H)
Resolution 1024x600 px
Display color 256K color
Visual angle 85/85/85/85
Backlight LED
Luminance 300cd/m²
LCD life 50000 hours
Touch panel 4-wire precision resistance network (surface hardness 4H)
CPUARM RISC 32Bit 792MHz
Memory 128MB Flash Memory+64MB Memory
RTC Built-in RTC
External storage 1 USB Host
Printer port USB Slave/Serial port
Ethernet 10/100M
Program download USB Slave(Micro USB)/Serial port/Ethernet
Communication COM0:RS232/RS485/RS422; COM1:RS485;COM2:RS232
